TitleBar Class

Provides common properties to customize the title bar, including attached properties for Window component.

Definition
 ​

[StyleTypedProperty(Property = StylePropertyName, StyleTargetType = typeof(TitleBarControl))]
[StyleTypedProperty(Property = ButtonStylePropertyName, StyleTargetType = typeof(TitleBarButton))]
[StyleTypedProperty(Property = BackButtonStylePropertyName, StyleTargetType = typeof(TitleBarButton))]
public static class TitleBar {...}

Inheritance: No inheritance for static classes.

Includes
 ​

This class includes the following attached properties and events:

Background
 ​

The background color of the title bar, which fills the entire title bar area, only works when the window is active.

  • Property: Attached

  • Type: Brush

  • Default value: null

Foreground
 ​

The foreground color of the title bar, which is used to colorize the text (title), only works when the window is active.

  • Property: Attached | Inherited

  • Type: Brush

  • Default value: Inherited

InactiveBackground
 ​

The same as Background, but only works when the window is inactive.

  • Property: Attached

  • Type: Brush

  • Default value: null

InactiveForeground
 ​

The same as Foreground, but only works when the window is inactive.

  • Property: Attached | Inherited

  • Type: Brush

  • Default value: Inherited

Style
 ​

The style of the title bar, which is used to customize the appearance of the title bar. However, this property is not recommended to use, you should use the Background, Foreground, InactiveBackground, and InactiveForeground properties to customize the title bar.

  • Property: Attached

  • Type: Style

  • Default value: null

ButtonStyle
 ​

The style of the title bar buttons, which is used to customize the appearance of the title bar buttons.

  • Property: Attached

  • Type: Style

  • Default value: null

IsIconVisible
 ​

Gets or sets whether the icon of the window will be visible in the left of the title bar, before the title.

  • Property: Attached

  • Type: bool

  • Default value: false

IsBackButtonVisible
 ​

Gets or sets whether the back button will be visible in the left of the title bar, before the icon.

  • Property: Attached

  • Type: bool

  • Default value: false

IsBackEnabled
 ​

Gets a value that indicates whether the back button is enabled or disabled.

True if the back button is enabled; otherwise, false.

  • Property: Attached

  • Type: bool

  • Default value: true

BackButton-[Command/CommandParameter/CommandTarget]
 ​

The necessary properties to bind a command to the back button. The back button is used to navigate back in the navigation history of the window.

If you prefer to use Click event instead of Command, you can use the BackRequested event.

****Property** Type**Default value
-CommandAttachedICommandnull
-CommandParameterAttachedobjectnull
-CommandTargetAttachedIInputElementnull

BackButtonStyle
 ​

The style of the back button, which is used to customize the appearance of the back button.

  • Property: Attached

  • Type: Style

  • Default value: null

ExtendViewIntoTitleBar
 ​

Gets or sets whether the client area of the window extends into the title bar area. This is quite useful when you want to create a custom title bar with custom controls.

If this property is set to true, the client area will be exactly the same size as the window, including the title bar area. If this property is set to false, the client area will be smaller than the window, excluding the title bar area. This

  • Property: Attached

  • Type: bool

  • Default value: false

SystemOverlayLeftInset
 ​

The width of the system overlay left inset, useful when you want to create a custom title bar with custom controls and want to avoid the system overlay area.

  • Property: Attached | Readonly

  • Type: double

  • Default value: 0 (changes based on the system)

SystemOverlayRightInset
 ​

The width of the system overlay right inset, useful when you want to create a custom title bar with custom controls and want to avoid the system overlay area.

  • Property: Attached | Readonly

  • Type: double

  • Default value: 0 (changes based on the system)

Height
 ​

The height of the title bar area.

  • Property: Attached

  • Type: double

  • Default value: 36

[Close/Minimize/Maximize]-ButtonAvailability
 ​

There are three buttons located in the title bar by default: minimize, maximize/restore, and close. You can customize these buttons by using the three properties in ui:TitleBar class as well:

  • ui:TitleBar.CloseButtonAvailability: The availability of the close button.

  • ui:TitleBar.MaximizeButtonAvailability: The availability of the maximize/restore button.

  • ui:TitleBar.MinimizeButtonAvailability: The availability of the minimize button.

As the word 'availability' means, you can control the visibility and enabled status of the buttons with these properties. You can choose one option from TitleBarButtonAvailability Enum.

Be careful when you hide the close button.

You can surely disable or hide the close button. But users can still close your window by pressing Alt+F4, using the task manager, clicking the close button on the taskbar or other methods.

If you really wish your window to be unclosable, you should consider handling the Window.Closing event after disabling the close button, and cancel the closing operation by setting Cancel property of CancelEventArgs to true.

For example, the following code will hide the minimize button and disable the close button:

ui:TitleBar.ButtonMinimizeAvailability="Collapsed"
ui:TitleBar.ButtonCloseAvailability="Disabled"

Window with hidden minimize button and disabled close button

Never hide only one of minimize button and maximize/restore button.

The example above is just for demonstration. Do not imitate it in your applications. According to the Fluent Design guidelines, you should always show both minimize and maximize/restore buttons together. If you hide one of them, the other one should be hidden as well.

Though we give you the full rights to customize your applications, it's not recommended since it might confuse users and break the consistency of the UI.

ButtonGlyphStyle
 ​

The button is disabled but visible. You can still see the button but cannot interact with it. You can choose from TitleBarButtonGlyphStyle Enum.

The null value means the style will be selected automatically based on the system.

BackRequested
 ​

Occurs when the back button is clicked.

  • Event: Attached

  • Handler: EventHandler<BackRequestedEventArgs>

Fields
 ​

(Dependency Properties)
 ​

The dependency properties listed above each have one DependencyProperty field.

(Routed Events)
 ​

The routed events listed above each have one RoutedEvent field.

Methods
 ​

(Dependency Properties)
 ​

The attached non-readonly dependency properties listed above each have a Get and Set method;

The attached readonly dependency properties listed above each have a Get method;

(Routed Events)
 ​

The attached routed events listed above each have an Add and Remove method;

Remarks
 ​

Component
 ​

This class is used to customize the title bar of the Window and TitleBarControl (internal) component.

See also
 ​

Source code
 ​
